Free Resource
Solid Tyre Catalogue and Size Charts
Get our complete product catalogue with full size charts, load tables, and specification sheets for all JABIL product lines.
What's in the JABIL Catalogue?
Our product catalogue is updated regularly and covers all current product lines. It is designed to help buyers, engineers, and procurement teams identify the right tyre for their equipment quickly.
Full Forklift Solid Tyre Size Chart
All sizes from 4.00-8 to 35/65-33+, with load capacities at 10, 16, and 26 km/h.
Press-on / Cushion Tyre Sizes
Standard sizes for electric sit-down forklifts and narrow-aisle equipment.
Polyurethane Wheel Catalogue
PU drive and load wheel dimensions and specifications for stackers and pallet trucks.
AWP Tyre Specifications
Scissor lift and boom lift tyre sizes with non-marking and anti-static options.
Rim & Accessory Reference
Compatible rim dimensions and accessory specifications.
Compound Guide
Explanation of compound options: standard black, non-marking, anti-static, cold storage.
50+ Export Countries
Shipping to importers and dealers worldwide
Download the Free Catalogue
Please fill in your details below. The catalogue download link will be provided immediately and sent to your email.
What the catalogue contains, section by section
The catalogue is a working document, not a brochure. It contains the dimensional and load data for every current JABIL product line, in the same format as the size tables on this website but collated for offline use and for sending to your own customers. It is updated as sizes and compounds change, so the version you download is the version we are currently manufacturing.
If you need a single size chart rather than the whole catalogue, the equivalent data is on the individual product pages and each size page — the catalogue simply gathers them into one file.
Contents of the catalogue
| Section | What it contains | Use it for |
|---|---|---|
| Forklift solid tyres | Full size chart with OD, section width, recommended rim and load at 10 / 16 / 26 km/h, split by drive and steer position | Matching a tyre to a counterbalance or warehouse truck |
| Press-on / cushion tyres | Size, OD, section width, band diameter and load at 10 and 16 km/h | Cushion-truck and reach-truck replacement |
| Polyurethane wheels | Drive and load wheel dimensions, durometer range and load capacity | Warehouse trucks, AGVs and castor applications |
| Aerial work platform tyres | Scissor and boom lift sizes with rim, OD, section width and reference load | Platform replacement and fleet specification |
| OTR / engineering solid tyres | Solid and press-on sizes for industrial and port equipment, with compound options | Port, terminal, scrap and construction equipment |
| Rims and accessories | Rim width pairings, bolt patterns and accessory references | Ordering a complete wheel rather than a tyre alone |
| Compound guide | Standard black, non-marking, anti-static, oil-resistant, cold-store and high-temperature formulations | Choosing the compound for a specific site or environment |
How to read the load tables
Most JABIL size tables publish load capacity at three speeds — 10, 16 and 26 km/h — and, for forklift tyres, separately for the drive axle and the steer axle. The reason is that load capacity falls as speed rises, and the drive axle carries more load than the steer axle on the same truck.
Where a size is available in more than one compound, the load rating may differ between compounds. If you are substituting a non-marking tyre for a black one, check the rating rather than assuming it carries over.
- Use the drive figure for the powered wheels and the steer figure for the free-rolling wheels. Do not apply one rating across the whole truck.
- Match the speed to the truck’s actual maximum operating speed, not to a nominal figure. A tyre rated at 10 km/h fitted to a truck that runs at 26 km/h is under-rated for the application.
- Derate for duty cycle — continuous running, long shifts and high ambient temperature all reduce safe capacity below the published number.
- Confirm against the machine plate before ordering. The published table is the tyre’s capability; the machine plate is the requirement. The lower of the two governs.
Which document do you actually need?
| Situation | Most useful document | Where to get it |
|---|---|---|
| Quoting a single size to a customer | The individual size page | Product section of this website |
| Building a wholesale offer across several sizes | Full catalogue PDF | Download form on this page |
| Checking what fits a specific machine brand | Brand fitment pages | Brands section of this website |
| Confirming a rim pairing | Rim pairing table | Rims and accessories page |
| Explaining compound choices to an end user | Compound guide section | Inside the catalogue PDF |
| Checking whether a size is in production | Current catalogue edition | Download form on this page |
Downloading and using the catalogue
Complete the form on this page and the download link is provided immediately, with a copy sent to your email so you can retrieve it later. The file is a PDF and works on desktop and mobile without additional software.
The catalogue may be shared with your own customers. It is not confidential in that sense — it is a specification document. The only restriction we ask is that the data is not altered and that JABIL is identified as the manufacturer.
If your requirement falls outside the published range, contact us rather than treating the catalogue as exhaustive. As a manufacturer we produce to drawing, and a size that does not appear in the current edition may still be producible on request.
Catalogue and document questions
Yes. Complete the download form and the link is provided immediately. There is no charge and no obligation.
It is revised as sizes, compounds and specifications change, which in practice means several times a year. The edition available on this page is the current manufacturing edition.
For wholesale and OEM enquiries, yes — Excel size lists can be supplied so you can work the data into your own pricing and stock systems. Request it with your enquiry.
No. Tyre prices move with raw-material and freight cost, so a printed price list would be out of date before it arrived. Prices are quoted per enquiry with an explicit validity window.
Send the details. Sizes outside the published range are frequently producible to drawing for OEM and volume orders, and we will tell you honestly if a size is not feasible rather than accept an order we cannot fill.
Get the catalogue or a specific size chart
Use the download form on this page for the full catalogue. For a specific size, a rim pairing or a compound question, email info@jabiltyre.com or message +86 137 0546 5224 on WhatsApp and we will send the relevant page rather than the whole document.
Where to go next
If you already know your size, the forklift solid tyre size pages list load capacities at 10, 16 and 26 km/h without waiting for a download. Buyers specifying electric trucks should start with the press-on tyre range; buyers fitting outdoor equipment should check the OTR solid tyre range. For compound selection, the guide to non-marking solid tyres covers where white compound is genuinely required and where it is not.
